SPSMJ5PCPipe Stand
The Max Jack Pipe Handling System is a versatile, heavy-duty solution designed to safely support, position, and maneuver large pipes during welding, fabrication, and fit-up operations. Engineered for durability and flexibility, the Max Jack features a robust ACME-thread height adjustment system, heavy-duty casters, and specialized wheels that help control pipe movement. With a maximum capacity of 5,000 lbs (2,265 kg) depending on configuration, this system provides reliable performance for demanding industrial applications. Its modular design allows it to be purchased as a complete kit—including jack, casters, and wheels—and supports multiple add-ons to accommodate a wide range of pipe handling requirements.
Key Features and Benefits of SPSMJ5PC
- High Load Capacity: Supports up to 5,000 lbs (2,265 kg) depending on configuration, making it suitable for heavy industrial pipe handling.
- Flexible Height Adjustment: Features a solid 1.75" ACME-thread adjustment for smooth and precise height control during pipe positioning.
- Dual Operating Height Options: Can operate with or without casters, allowing users to adjust the working height based on the job site requirements.
- Heavy-Duty Swivel Casters: Equipped with 8" urethane-over-steel casters with solid hubs, providing enhanced safety, durability, and mobility.
- Pipe Travel Reduction Wheels: 1.5" wide steel or phenolic wheels help reduce unwanted pipe movement during alignment or welding.
- Wide Pipe Diameter Range: Accommodates pipes from 1 inch to 36 inches (25.4 mm – 914.4 mm) in diameter, making it suitable for various pipe sizes.
- Complete System Availability: Can be purchased as a complete kit including jack, casters, and wheels for convenient setup and operation.
- Multiple Wheel Options: Turning wheels are available in steel, stainless steel, and phenolic, offering flexibility for different environments and applications.
- Expandable System with Add-Ons: Compatible with various accessories including stainless steel sleeves for contamination-free fit-up, hold-down chain devices for transport, and ball transfer attachments for versatile pipe movement.
Specifications of SPSMJ5PC
- Product Name: Max Jack
- Maximum Capacity: 5,000 lbs / 2,265 kg (depending on configuration)
- Operating Height (with swivel casters): 32 – 44 in / 812.8 – 1,117.6 mm
- Operating Height (jack only): 24 – 36 in / 609.6 – 914.4 mm
- Pipe Diameter Range: 1 – 36 in / 25.4 – 914.4 mm
- Height Adjustment: Solid 1.75" ACME-thread adjustment
- Casters: 8" urethane over steel with solid hub
- Wheels: 1.5" wide steel or phenolic turning wheels
Properties of SPSMJ5PC
- Product Type: Pipe Handling Jack System
- Application: Pipe welding, fit-up, alignment, and fabrication
- Material: Heavy-duty steel construction
- Mobility: Swivel casters with solid hubs
- Adjustment Mechanism: ACME threaded height adjustment
- Wheel Options: Steel, stainless steel, phenolic
- Pipe Size Compatibility: 1" – 36" pipes
- Optional Accessories: Stainless sleeves, hold-down chains, ball transfer attachments
- Configuration Options: Jack only or complete kit with casters and wheels
